IFRM 06P17A1/S35L Miniature Inductive Proximity Switch
IFRM 06P17A1/S35L
- 2 mm
- PNP make function (NO)
- connector M8
- -25 ? 75 ?C
- IP 67
Safe shopping
Your data is always protected
Sale_coupon_15
1.955,00 EGP
Out of stock
Out of stock
11
People watching this product now!
-
Return within 14 days
Payment Methods:
Description
IFRM 06P17A1/S35L Miniature Inductive Proximity Switch
| Attribute | Value |
| Sensor Technology | Inductive |
| Body Style | Barrel |
| Output Type | PNP-NO |
| Detection Range | 2 mm |
| Terminal Type | M8 – 3 Pin |
| Supply Voltage | 10 ? 30 V dc |
| Length | 46mm |
| Width | 6.5mm |
| Maximum DC Voltage | 30V |
| Mounting Type | Flush Mount |
| IP Rating | IP67 |
| Switching Current | 200 mA |
| Housing Material | Stainless Steel |
| Short Circuit Overload Protection | Yes |
| Reverse Polarity Protection | Yes |
| Maximum Switching Frequency | 5kHz |
| Shielding | Shielded |
| Minimum Operating Temperature | -25?C |
| Standards Met | CE, cULus Listed, EAC |
| Maximum Operating Temperature | +75?C |
