DM542 Stepper Motor Driver 4.2A, 18-50Vdc
DM542 Stepper Motor Driver 4.2A, 18-50Vdc
- Input voltage 18-50VDC.
- Output current programmable, from 1A to 4.2A.
- Pulse input frequency up to 200 KHz.
- Suitable for 2-phase and 4-phase motors.
- TTL compatible and optically isolated input.
- Support PUL/DIR and CW/CCW modes.
- Operating Temperature : 70 C.
Safe shopping
Your data is always protected
Sale_coupon_15
2,000.00EGP
In stock
In stock
15
People watching this product now!
-
Return within 14 days
Payment Methods:
Description
DM542 Stepper Motor Driver 4.2A, 18-50Vdc
The DM542 is a fully digital stepper drive developed with advanced DSP control algorithm based on the latest motion control technology. It has achieved a unique level of system smoothness, providing optimal torque and nulls mid-range instability. Its motor auto-identification and parameter auto-configuration feature offers quick setup to optimal modes with different motors. Compared with traditional analog drives, DM542 can drive a stepper motor at much lower noise, lower heating, and smoother movement. Its unique features make DM542 an ideal choice for high requirement applications.
Specifications:
- DM542 Stepper Motor Driver.
- Anti-Resonance, provides optimum torque and nulls mid-range instability.
- Input voltage 18-50VDC.
- Output current programmable, from 1A to 4.2A.
- Pulse input frequency up to 200 KHz.
- Suitable for 2-phase and 4-phase motors.
- Automatic idle-current reduction.
- Over-voltage, over-current protection.
- TTL compatible and optically isolated input.
- Support PUL/DIR and CW/CCW modes.
- Operating Temperature : 70 C.
Power and Motor Terminal Assignments
   Terminal No. |    Terminal Name | Description |
Terminal 1 | +Vdc | Â Â Â Power supply, 20~30 VDC, Including voltage fluctuation and EMF voltage. |
Terminal 2 | GND | Power ground |
Terminal 3 | A+ | Motor Phase A+ |
Terminal 4 | A- | Motor Phase A- |
Terminal 5 | B+ | Motor Phase B+ |
Terminal 6 | B- | Motor Phase B- |
Pulse and Direction Inputs
   Terminal No. |    Terminal Name | Description |
Terminal 1 | PUL+ | Pulse +ve input |
Terminal 2 | PUL- | Pulse -ve input |
Terminal 3 | DIR+ | Â Â Â Direction +ve input |
Terminal 4 | DIR- | Direction -ve input |
Terminal 5 | ENA+ | Enable +ve input |
Terminal 6 | ENA- | Enable -ve input |
