BTS7960 43A High-power DC Motor Driver Module
BTS7960 43A High-power DC Motor Driver Module
- Double BTS7960 large current (43 A) H bridge driver
- 5V isolate with MCU, and effectively protect MCU
- 5V power indicator on board
- voltage indication of motor driver output end
- can solder heat sink
- Overvoltage lock up
- Undervoltage shut-down
- Overtemperature protection
- Current limitation
- Short-circuit protection
- Just need four lines from MCU to driver module (GND. 5V. PWM1. PWM2)
- isolation chip 5 V power supply (can share with MCU 5 V)
- Able to reverse the motor forward, two PWM input frequency up to 25kHZ
- two heat flow passing through an error signal output
- isolated chip 5V power supply (can be shared with the MCU 5V), can also use the on-board 5V supply
- the supply voltage 5.5V to 27V
- Dimension: 50 x 50 x 43 mm (LxWxH)
Safe shopping
Your data is always protected
Sale_coupon_15
525.00EGP
In stock
In stock
18
People watching this product now!
-
Return within 14 days
Payment Methods:
Description
BTS7960 43A High-power DC Motor Driver Module
This driver uses Infineon chips BTS7960 composed of high-power drive full H-bridge driver module with thermal over-current protection. Double BTS7960 H-bridge driver circuit, with a strong drive and braking, effectively isolating the microcontroller and motor driver! High-current 43A It is part of the NovalithICTM family containing one p-channel highside MOSFET and one n-channel lowside MOSFET with an integrated driver IC in one package. Due to the p-channel highside switch the need for a charge pump is eliminated thus minimizing EMI. Interfacing to a microcontroller is made easy by the integrated driver IC which features logic level inputs, diagnosis with current sense, slew rate adjustment, dead time generation and protection against overtemperature, overvoltage, undervoltage, overcurrent and short circuit
Features:
- Double BTS7960 large current (43 A) H bridge driver
- 5V isolate with MCU, and effectively protect MCU
- 5V power indicator on board
- voltage indication of motor driver output end
- can solder heat sink
- Overvoltage lock up
- Undervoltage shut-down
- Overtemperature protection
- Current limitation
- Short-circuit protection
- Just need four lines from MCU to driver module (GND. 5V. PWM1. PWM2)
- isolation chip 5 V power supply (can share with MCU 5 V)
- Able to reverse the motor forward, two PWM input frequency up to 25kHZ
- two heat flow passing through an error signal output
- isolated chip 5V power supply (can be shared with the MCU 5V), can also use the on-board 5V supply
- the supply voltage 5.5V to 27V
- Dimension: 50 x 50 x 43 mm (LxWxH)
Packing list:
- 1x BTS7960 Motor Driver Module 43A
