5Inch Touch Display DMT48270M050-02WT | DWIN
Safe shopping
Your data is always protected
Sale_coupon_15
2,750.00 EGP
In stock
In stock
10
People watching this product now!
-
Return within 14 days
Payment Methods:
Description
The DWIN DMT48270M050-02WT is a high-quality, industrial-grade 5.0-inch smart HMI (Human-Machine Interface) touch display designed for embedded systems and industrial automation. Driven by DWIN’s proprietary DGUS II system, it offloads all graphics processing from your main microcontroller.
📐 Display Specifications
- Screen Size: 5.0 Inches
- Resolution: 480 × 272 pixels (16:9 widescreen) [1]
- Color Depth: 16-bit, 65K colors [1]
- Panel Type: TN LCD with Resistive Touch (highly reliable in dusty or gloved industrial environments) [1]
- Backlight Lifespan: >20,000 hours [1]
⚙️ Hardware & Interfaces
- Microcontroller Interface: Serial UART (TTL/CMOS) for direct connection to Arduino, STM32, ESP32, or Raspberry Pi.
- Operating Voltage: 4.5V to 5.5V (Typically 5V).
- On-Board Flash Memory: 16MB for storing UI images, fonts, audio files, and custom animations.
- SD Card Slot: Used for uploading firmware, user interface (UI) design projects, and system files.
💻 Software & GUI Design
- DGUS Tool Software: Design your complete graphical user interface visually (drag-and-drop buttons, sliders, graphs, and text boxes) without writing rendering code.
- Zero-Code UI Development: The display handles the graphics; your external microcontroller only sends and receives simple hex commands via serial to read touch inputs or update variables.
