1Kg Load Cell Weight Sensor

1Kg Load Cell Weight Sensor

The Sensor is made from an aluminum-alloy and is capable of reading a capacity of 1KG and?designed to measure force in one direction. They will often measure force in other directions, but the sensor sensitivity will be different, since parts of the load cell operating under compression are now in tension, and vice versa

• Material: Aluminum
• Dimensions: 75?12.7?12.7mm
• Range: 1kg
• Rated output 1.0 ? 0.1mV / V
• Operating temperature:?-20??~?+85?
• Ambient Humidity:?10%?-80RH
• Voltage?range:?2.6?~?5.5V
• Weight:?32g

Package includes:

• 1 x Weighing Sensor
